Bitwise Rotation and Counting

Bit rotation is the operation of moving bits around a fixed-size variable in a circular manner. Unlike standard shifts that discard bits, rotations wrap the bits around to the opposite end.

• Rotate Left: Move bits to the left; overflowed bits re-enter from the right.
• Rotate Right: Move bits to the right; underflowed bits wrap back to the left.

These are cyclic operations, useful for pattern matching, compact encoding, or simulating certain hardware behaviors.

Rotation Example (8-bit)

Start with this value: 0b11010100 (212 in decimal)

Example 1: Rotate Left by 3

Original   : 11010100
Step 1     : Shift Left by 3    → 10100000
Step 2     : Wrap Right 3 bits  →      110
Result     : 10100000 | 00000110 = 10100110 (0xA6)

C code:
uint8_t val = 0b11010100;
uint8_t result = (val << 3) | (val >> (8 - 3));
result &= 0xFF;  // Ensure 8-bit result

Example 2: Rotate Right by 2

Original   : 11010100
Step 1     : Shift Right by 2   → 00110101
Step 2     : Wrap Left 2 bits   →       00
Result     : 00110101 | 00000000 = 00110101 (0x35)

C code:
uint8_t val = 0b11010100;
uint8_t result = (val >> 2) | (val << (8 - 2));
result &= 0xFF;  // Ensure 8-bit result

Pattern Detection Use Case

If you’re scanning a byte to detect a recurring bit sequence (like 0b0101), you can rotate the byte and check each rotated value:

for (int i = 0; i < 8; i++) {
    if ((byte & 0x0F) == 0x05) {
        // Match found
    }
    byte = (byte << 1) | (byte >> 7);
    byte &= 0xFF;
}

Relevance in Embedded/Firmware

• Crypto algorithms use bit rotation in hashing or key schedules.
• Sensor input decoding (like rotary encoders) may need circular bit checks.
• Efficient status flag compression, binary encoding, or circular buffer indexing.
• Pattern detection in protocol parsing, bitstreams, or error codes.

Bit rotation helps reduce logic and cycles when solving low-level tasks with tight memory and performance constraints.

Bit Counting & Power-of-Two Checks

Bit-level operations can be used not only to modify bits, but also to analyze them. This includes:

1. Counting Set Bits (1s) in a number
2. Checking if a number is a power of two
3. Identifying the position of the highest set bit

These operations are extremely common in firmware optimization, buffer management, error detection, and bitfield analysis.

1. Count Set Bits (also called Hamming Weight)

What it means: Count how many 1s are present in the binary form of a number.

Example:

uint8_t val = 0b11010100 → There are 4 set bits → Output = 4

Efficient loop:

int count = 0;
while (val) {
    count += (val & 1);
    val >>= 1;
}

2. Check if a Number is Power of Two

A number is a power of two only if it has exactly one bit set.

Bit trick:

if (n != 0 && (n & (n - 1)) == 0)
    // n is power of 2

Explanation: (n & (n - 1)) clears the lowest set bit. If the result is 0, only one bit was set in n.

3. Keep Only the Highest Set Bit

Sometimes you want to reduce a number to just its highest set bit (like 0b10000000 for 212).

Example:

int pos = -1;
while (n > 0) {
    pos++;
    n >>= 1;
}
// 'pos' holds the position of the highest set bit

Embedded Relevance

These tricks are widely used in embedded systems:

• Bitfield parsing: Count active flags
• Sensor decoding: E.g., active pin status count
• Task scheduling: Find the highest-priority task (e.g., via MSB set)
• Memory allocation/page alignment
• Buffer size optimization: Round up to nearest power-of-two size

They enable low-overhead implementations without loops or heavy library functions.
